Programmable Linear Power Supplies, UDP3305C 3Ch Advanced-Series Programmable Linear DC Power Supply

  UDP3000/S Series, Programmable Linear Power Supplies: Maximum power output: 328W. Four channel independent output: CH1/CH2: 0-30V/5A, CH3: 0-6V/3A, and CH4: 5V/2A. Multiple layers of protection: OCP, OVP, and OTP. Excellent load and line regulation. Extremely low output ripple and noise. Support one-key serial and parallel output functions. The 4.3-inch TFT display supports three channels and various parameters at the same time. List/delay function for controlling voltage and current output as needed. External trigger function for industrial automation control. Provide USB host, USB device, LAN, RS232, digital I/O, and other interfaces. The waveform display function allows for real-time and dynamic display of the output voltage, current, and power waveforms. Intelligent fan speed control can effectively reduce fan noise while in operation. Supports file storage and transfer in 10 groups, as well as USB flash read and write. High-accuracy display of five-digit voltage and four-digit current, with resolutions of 10 mV / 1 mA and 1 mV / 1 mA. Use the keyboard lock feature to guard against errors. Support for SCPI remote command control.
