Digital Multimeters, UT107+, Automitive Multimeters High Precision True RMS Automobile
SKU: UT107-plus
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
For testing and diagnosing both conventional and hybrid automobiles, the UT107+ is a high-precision True RMS automotive digital multi meter.
It can measure AC/DC voltage up to 1000V and AC/DC current up to 10A, with a maximum measurement time of 10 seconds for 20A.
In addition to capacitance, temperature, resistance, frequency, and duty cycle monitoring, the UT107+ has specialized automotive features including RPM, dwell angle, pulse width, and 12V battery testing.
It is appropriate for professional automobile diagnostics, maintenance, and electrical troubleshooting because to its additional features, which include VFC voltage measurement, data hold, relative mode, backlight, and high-voltage and large-current alerts.
Buy currently uses Select Automation shop pricing and checkout.
Features:
True RMS measurement.
Measures DC voltage up to 1000 V.
Measures AC voltage up to 1000 V.
Measures DC current up to 10 A.
Measures AC current up to 10 A.
20 A AC/DC current measurement for a maximum of 10 seconds.
VFC voltage measurement up to 1000 V.
Measures resistance.
Measures capacitance.
Measures frequency.
Measures temperature.
Measures duty cycle.
Measures pulse width up to 999.9 ms.
RPM measurement for 2-stroke and 4-stroke engines.
Dwell angle measurement for 1-to-8-cylinder engines.
12 V battery test function.
Diode testing function.
Transistor testing function.
Continuity testing function with audible buzzer.
Data hold function.
Relative measurement mode.
Manual ranging function.
Backlight function.
High-voltage alarm function.
High-voltage overload alarm function.
Large-current alarm function.
Low-battery indication.
Automatic power-off function.
6000-count display.
Input protection.
Suitable for conventional vehicle diagnostics and maintenance.
Suitable for hybrid vehicle testing and troubleshooting.
Suitable for automotive electrical system testing.
Suitable for testing fuses, switches, solenoids and relays.
Suitable for charging system, fuel system and engine sensor testing.
Suitable for engine RPM, dwell angle and pulse width testing.
Specifications:
DC Voltage: 600 mV / 6 V / 60 V / 600 V / 1000 V.
DC Voltage Accuracy: ± (0.5% + 3).
AC Voltage: 6 V / 60 V / 600 V / 1000 V.
AC Voltage Accuracy: ± (0.8% + 3).
AC Current: 6 mA / 60 mA / 600 mA / 10 A; 20 A for 10 seconds maximum.
AC Current Accuracy: ± (1.0% + 8).
DC Current: 6 mA / 60 mA / 600 mA / 10 A; 20 A for 10 seconds maximum.
DC Current Accuracy: ± (0.8% + 8).
Resistance: 600 Ω / 6 k Ω / 60 k Ω / 600 k Ω / 6 MΩ / 60 MΩ.
Resistance Accuracy: ± (0.8% + 3).
Capacitance: 6 nF / 60 nF / 600 nF / 6 μF / 60 μF / 600 μF / 6 mF / 60 mF / 100 Mf.
Capacitance Accuracy: ± (3% + 10).
Frequency: 10 Hz–10 MHz
Frequency Accuracy: ± (0.1% + 5).
Temperature: -40°C to 1000°C.
Temperature Accuracy: ± (1.0% + 3).
VFC Voltage: 1000 V.
VFC Accuracy: ± (2.0% + 10).
RPM: 2-stroke and 4-stroke engines.
RPM Accuracy: ± (3.0% + 5) for 2-stroke; ±(3.0% + 3) for 4-stroke.
Dwell Angle: 1-to-8-cylinder engines.
Dwell Angle Accuracy: ± (3.0% + 5).
Pulse Width: 999.9 ms.
Pulse Width Accuracy: ± (1.5% + 10).
12 V Battery Test: Yes.
Display Count: 6000.
Manual Range: Yes.
True RMS: Yes.
Data Hold: Yes.
MAX/MIN/Relative Mode: Yes.
Duty Cycle: Yes.
Continuity/Diode/Transistor Testing: Yes.
Backlight: Yes.
Auto Power-Off: 15 minutes.
Low-Battery Indication: Below 2.4 V.
Power Supply: 2 × 1.5 V AAA batteries.
Product Dimensions: 183 × 88 × 56 mm.
