Digital Multimeters, UT15B MAX, Max True RMS Digital Multimeters
SKU: UT15B-MAX
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The UT15B MAX is a True RMS digital multi meter that allows for quick, accurate, and dependable electrical and electronic measurements.
It has a compact and portable design, excellent EMC anti-interference performance, and full-range input protection.
The UT15B MAX can detect AC/DC voltage up to 1000V, current up to 10A, resistance up to 60MΩ, capacitance up to 6000μF, and frequency up to 10 MHz
It also supports VFD voltage measuring, continuity and diode testing, data hold, MAX/MIN, relative mode, adjustable backlight, auto-ranging, and audio and visual alarms.
The meter comes with both standard and fine-tipped gold-plated test leads and is ideal for electrical and electronic engineers, maintenance professionals, and general troubleshooting tasks.
Buy currently uses Select Automation shop pricing and checkout.
Features:
True RMS measurement.
Measures DC voltage up to 1000 V.
Measures AC voltage up to 1000 V.
Measures AC current up to 10 A.
Measures DC current up to 10 A.
Measures resistance up to 60 MΩ.
Measures capacitance up to 6000 μF.
Measures frequency up to 10 MHz
Measures duty cycle from 1% to 99.9%.
VFD voltage measurement up to 600 V.
Continuity testing function.
Diode testing function.
Data hold function.
MAX/MIN measurement function.
Relative measurement mode.
Adjustable LCD backlight.
Auto ranging and manual ranging functions.
Audible and visual alarm function.
Mis-plug alarm function.
Any-key wake-up function.
Low-battery indication.
Automatic power-off function.
Strong EMC anti-interference performance.
Full-range input protection.
Compact and portable design.
Supplied with standard and fine-tipped gold-plated test leads.
Suitable for electrical and electronic engineers.
Suitable for electrical maintenance and troubleshooting.
Suitable for general electrical and electronic testing.
Specifications:
Meter Type: True RMS Digital Multi meter.
DC Voltage: 600.0 mV / 6.000 V / 60.00 V / 600.0 V / 1000 V.
DC Voltage Accuracy: ± (0.4% + 3).
AC Voltage: 600.0 mV / 6.000 V / 60.00 V / 600.0 V / 1000 V.
AC Voltage Accuracy: ± (0.5% + 5).
VFD Voltage: 600.0 V.
VFD Voltage Accuracy: ±8%.
AC Current: 600.0 μA / 6000 μA / 60.00 mA / 600.0 mA / 6.000 A / 10.00 A.
AC Current Accuracy: ± (1.2% + 3).
DC Current: 600.0 μA / 6000 μA / 60.00 mA / 600.0 mA / 6.000 A / 10.00 A.
DC Current Accuracy: ± (1.2% + 3).
Resistance: 600.0 Ω / 6.000 k Ω / 60.00 k Ω / 600.0 k Ω / 6.000 MΩ / 60.00 MΩ.
Resistance Accuracy: ± (0.5% + 2).
Capacitance: 6.000 nF / 60.00 nF to 600.0 μF / 6000 μF.
Capacitance Accuracy: ± (2.0% + 5).
Frequency: 10 Hz–10 MHz
Frequency Accuracy: ± (0.1% + 3).
Duty Cycle: 1%–99.9%.
Duty Cycle Accuracy: ± (1.0% + 4).
Display Count: 6000.
True RMS: Yes.
Continuity/Diode Test: Yes.
Data Hold: Yes.
MAX/MIN: Yes.
Relative Mode: Yes.
Backlight: Adjustable.
Auto/Manual Range: Yes.
Auto Power-Off: Yes.
Low-Battery Indication: Yes.
Audible & Visual Alarm: Yes.
Mis-Plug Alarm: Yes.
Any-Key Wake-Up: Yes.
Input Protection: Full range.
Power Supply: 2 × 1.5 V AA batteries.
Product Dimensions: 182 × 91 × 45 mm.
