Digital Clamp Meters, UT200B+, 600A Digital Clamp Multimeter AC/DC Voltage Detector Frequency Resistance Tester
SKU: UT200B-plus
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The UT200B+ Digital Clamp Multi meter is a small True RMS clamp meter intended for routine electrical testing, repair, and maintenance.
It measures AC current (up to 600 A), AC/DC voltage, resistance, capacitance, and frequency. Its clamp design allows current measurements without disconnecting the circuit, and the LIVE function, high-voltage alert, and illumination make it easier to solve electrical issues.
The UT200B+ is appropriate for electricians, home appliance maintenance, DIY enthusiasts, and general electrical testing.
Buy currently uses Select Automation shop pricing and checkout.
Features:
True RMS measurement.
Measures AC current up to 600 A.
Measures AC/DC voltage up to 600 V.
Measures resistance.
Measures capacitance.
Measures frequency.
Continuity and diode testing.
LIVE function for live-wire detection.
High-voltage warning.
Audible and visual alarm functions.
Auto-ranging function.
Data hold function.
LCD backlight.
Built-in flashlight.
Low-battery indication.
3000-count display.
28 mm jaw opening.
CAT III 600 V safety rating.
Compact handheld design.
Suitable for electrical repair and maintenance.
Suitable for household electrical equipment testing and DIY applications.
Specifications:
Product Type: True RMS Digital Clamp Multi meter.
AC Current Measurement Range: 3.000 A / 30.00 A / 600.0 A.
AC Current Accuracy: ± (4%+10) at 3.000 A; ± (4%+5) at 30.00 A and 600.0 A.
AC Voltage Measurement Range: 3.000 V–600 V.
AC Voltage Accuracy: ± (1.2%+5).
DC Voltage Measurement Range: 3.000 V–300.0 V / 300.0 V–600 V.
DC Voltage Accuracy: ± (1.0%+5) / ± (1.0%+3).
Resistance Measurement Range: 300.0 Ω–300.0 kΩ / 300.0 kΩ–3.000 MΩ.
Resistance Accuracy: ± (1.0%+5) / ± (2.0%+5).
Capacitance Measurement Range: 30.00 nF–300.0 nF / 3.000 μF–300.0 μF / 1.000 mF.
Capacitance Accuracy: ± (4%+10) / ± (4%+5) / ± (5%+10).
Frequency Measurement Range: 10 Hz–10 kHz.
Frequency Accuracy: ± (1.0%+5).
True RMS: Yes.
Display Count: 3099.
Jaw Opening: 28 mm.
Auto Range: Yes.
Continuity Test: Yes.
Diode Test: Yes.
LIVE Function: Yes.
High-Voltage Warning: Yes.
Data Hold: Yes.
LCD Backlight: Yes.
Flashlight: Yes.
Safety Rating: CAT III 600 V.
Power Supply: 2 × 1.5 V R03 batteries.
Application: Electrical testing, repair, maintenance, household equipment troubleshooting and DIY electrical work.
