Digital Clamp Meters, UT219PV, Professional AC/DC Clamp Meter
SKU: UT219PV
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
A professional True RMS AC/DC clamp meter made especially for high-voltage photovoltaic settings is the UT219PV.
Accurate measurements of AC/DC voltage and current, low-pass filtered voltage and current, inrush current, peak current, DC power, resistance, continuity, diodes, capacitance, and temperature are all provided.
In addition to Bluetooth 5.0 connectivity and compatibility with the optional UT-CS09D flexible clamp sensor for AC current measurements up to 3000 A, the UT219PV boasts an incredibly thin 35 mm jaw made for usage in confined locations like photovoltaic inverters and combiner boxes.
Large motors, solar systems, energy storage systems, UPS systems, and other high-voltage electrical applications can all benefit from it.
Buy currently uses Select Automation shop pricing and checkout.
Features:
True RMS measurement.
Measures AC current up to 999.9 A.
Measures DC current up to 999.9 A.
Measures AC voltage up to 1500 V.
Measures DC voltage up to 2500 V.
Measures DC millivoltage up to 999.9 mV.
Measures DC power up to 2500 kVA.
Measures resistance.
Measures capacitance.
Measures frequency.
Measures temperature.
Low-pass filtered AC voltage measurement.
Low-pass filtered AC current measurement.
Inrush current measurement.
Peak measurement function.
Solar panel polarity indication with audible and visual alarm when DC voltage is below -10 V.
High-voltage alarm function.
Over-range indication.
AUTO HOLD function.
Bluetooth 5.0 connectivity and app support.
Compatible with the optional UT-CS09D flexible clamp sensor.
Flexible clamp sensor allows AC current measurement up to 3000 A.
Ultra-thin 35 mm clamp jaw for narrow spaces.
Dual LCD display for simultaneous voltage and current readings.
Auto backlight function.
Low-battery indication.
Auto power-off function.
Diode testing function.
IP65-rated protection.
Suitable for photovoltaic power station testing.
Suitable for solar inverter and combiner box testing.
Suitable for energy storage system testing.
Suitable for UPS system testing.
Suitable for large motor testing and maintenance.
Suitable for high-voltage electrical installation and maintenance.
Specifications:
AC Current: 999.9 A.
AC Current Accuracy: ± (2.0% + 5) at 40 Hz–100 Hz; ± (2.5% + 5) at 100 Hz–1000 Hz.
DC Current: 999.9 A.
DC Current Accuracy: ± (2.0% + 5).
AC Voltage: 999.9 V / 1500 V.
AC Voltage Accuracy: ± (1.0% + 5).
DC Voltage: 999.9 V / 2500 V.
DC Voltage Accuracy: ± (1.0% + 5).
DC Millivoltage: 999.9 mV.
DC Millivoltage Accuracy: ± (1.0% + 5).
AC Voltage with LPF: 999.9 V.
AC Voltage with LPF Accuracy: ± (2.0% + 9).
AC Current with LPF: 999.9 A.
AC Current with LPF Accuracy: ± (2.5% + 9).
AC Current with Flexible Clamp Sensor: 30.00 A / 300.0 A / 3000 A.
Flexible Clamp Sensor Accuracy: ± (3.0% + 5).
AC Current with LPF and Flexible Clamp Sensor Accuracy: ± (4.0% + 9).
DC Power: 999.9 kVA / 2500 kVA.
DC Power Accuracy: ± (2.0% + 20).
Frequency: 5.0 Hz–999.9 Hz.
Frequency Accuracy: ± (0.5% + 5).
Resistance: 999.9 Ω / 9.999 k Ω / 99.99 k Ω.
Resistance Accuracy: ± (1.0% + 5).
Capacitance: 100.0 μF / 1000 μF.
Capacitance Accuracy: ± (1.0% + 5).
Temperature: -40°C to 400°C / -40°F to 752°F.
Temperature Accuracy: ± (1.0% + 30) / ± (1.0% + 60).
Display Count: 9999.
Display: Dual LCD display (V+A).
Maximum Jaw Opening: 35 mm.
True RMS: Yes.
Inrush Current: Yes.
Peak Measurement: Yes.
Solar Panel Polarity Indication: Yes, below -10 V DC.
Bluetooth: Bluetooth 5.0.
Flexible Clamp Compatibility: UT-CS09D, optional.
Maximum Flexible Clamp Current: 3000 A AC.
IP Rating: IP65.
Power Supply: 2 × AA batteries.
Dimensions: 295 × 73 × 50 mm.
