Acoustic Imager, UT225A, Wireless High & Low Voltage Transformer Turns Ratio Testers
SKU: UT225A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The UT225A Wireless High & Low Voltage Transformer Turns Ratio Tester is a professional portable testing equipment that allows for speedy on-site testing of current transformers in metering installations.
It measures primary and secondary current, as well as transformer turns ratio, and assists in determining phase type and polarity.
The UT225A is intended for usage in 380V/220V power systems and offers wireless transmission, excellent anti-interference performance, high measurement accuracy, and data storage for up to 3,000 measurement groups.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Designed for quick on-site current transformer testing.
Measures primary and secondary current.
Measures transformer turns ratio.
Identifies phase type and polarity.
Wireless transmission up to 100 m.
Strong anti-interference capability.
High measurement accuracy.
Stores up to 3,000 measurement groups.
Data retention and review functions.
Automatic power-off after approximately 15 minutes.
Flexible primary current clamp.
Suitable for 380V/220V power systems.
Specifications:
Product Type: Wireless Transformer Turns Ratio Tester.
Primary Current: AC 0.0A–3000A.
Primary Current Accuracy: ±1% FS.
Primary Current Resolution: 0.1A.
Secondary Current: AC 0.00mA–5A.
Secondary Current Resolution: 0.01mA
Secondary Current Accuracy: ±0.5% FS
Online Measurement Voltage: 380V/220V Power System.
Turns Ratio Measurement: 1–500.
Sampling Rate: 3 times/second.
Wireless Transmission Distance: Up to 100 m.
Secondary Clamp Cable Length: 2 m.
Data Retention: Yes.
Data Review: Yes.
Overflow Indication: Yes, OL symbol.
No Signal Indication: Yes.
Power Supply: 4 × 1.5V AAA batteries.
Operating Time: 30 hours.
Main Meter Dimensions: 78 × 165 × 42 mm.
Primary Current Clamp Jaw Size: Ø200 mm.
Primary Current Clamp Dimensions: 200 × 370 × 40 mm.
Secondary Current Clamp Jaw Size: Ø8 mm.
Secondary Current Clamp Dimensions: 137 × 40 × 19.5 mm.
