Acoustic Imager, UT225B, Wireless High & Low Voltage Transformer Turns Ratio Testers
SKU: UT225B
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The UT225B Wireless High & Low Voltage Transformer Turns Ratio Tester is intended for rapid, on-site testing of current transformers in metering installations.
It monitors primary current, secondary current, and transformer turns ratio while also determining phase type and polarity.
The UT225B can perform online measurements on systems up to 35 kV and uses wireless transmission between the primary current clamp and the main tester, making it ideal for use in substations, power plants, industrial facilities, electrical inspection, and maintenance.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Online measurement voltage of up to 35 kV.
Primary high-voltage current measurement from 0.0 A to 800 A.
Secondary low-voltage current measurement from 0.00 mA to 5 A.
Transformer turns-ratio measurement from 1 to 500.
Measures primary and secondary current and determines turns ratio.
Identifies phase type and polarity.
Strong anti-interference capability for reliable measurements.
Wireless transmission from the primary current clamp up to 100 m.
Stores up to 3,000 measurement groups.
Data retention and data review functions.
USB communication for data upload.
Automatic range switching.
Overflow indication using "OL" display.
No-signal indication.
Automatic power-off after approximately 15 minutes.
Includes an insulation rod with a withstand voltage of up to 110 kV.
Specifications:
Primary Current: 0.0 A–800 A.
Primary Current Resolution: 0.1 A.
Primary Current Accuracy: ±0.5% FS.
Secondary Current: 0.00 mA–5 A.
Secondary Current Resolution: 0.01 mA.
Secondary Current Accuracy: ±0.5% FS.
Online Measurement Voltage: Up to 35 kV.
Turns Ratio Measurement: 1–500.
Turns Ratio Resolution: 0.1.
Sampling Rate: 3 times/second.
Wireless Transmission Distance: Up to 100 m.
Secondary Current Clamp Cable Length: 2 m.
Data Retention: Yes.
Data Review: Yes.
Data Upload: USB communication.
Overflow Display: Yes, "OL".
No-Signal Indication: Yes.
Power Supply: 4 × 1.5 V AAA batteries.
Operating Time: 30 hours.
Insulation Rod Withstand Voltage: 110 kV.
Main Meter Dimensions: 78 × 165 × 42 mm.
Primary High-Voltage Current Clamp Jaw: Ø48 mm.
Primary Clamp Dimensions: 76 × 255 × 31 mm.
Secondary Low-Voltage Current Clamp Jaw: Ø8 mm.
Secondary Clamp Dimensions: 137 × 40 × 19.5 mm.
Insulation Rod: Ø32 mm; 1 m per section, 5 sections.
