Digital Clamp Meters, UT268B, Wireless Large Current Fork Meter
SKU: UT268B
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The UT268B is a multipurpose, intelligent, high-precision large-current fork meter intended for power system testing and industrial electrical measurement.
Three-phase voltage, current, phase, frequency, and power—including apparent power, reactive power, active power, and power factor—are all measured.
In addition, the UT268B can detect inductive and capacitive loads, measure phase sequence, identify transformer windings, and spot improper wiring in three-phase three-wire and three-phase four-wire systems.
It is appropriate for electrical power distribution, industrial maintenance, and electrical system diagnostics because of its big 50 mm jaw opening, integrated rechargeable lithium battery, data storage, and huge LCD display.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Measures AC voltage from 0.00 V to 600 V.
Measures AC current up to 1000 A.
Measures three-phase voltage and current.
Measures phase angle from 0° to 360°.
Measures active power up to 600 kW.
Measures reactive power up to 600 kVAR.
Measures apparent power up to 600 kVA.
Measures power factor from -1 to +1.
Measures frequency from 45 Hz to 65 Hz.
Measures phase sequence of the power grid.
Measures active, reactive and apparent power.
Measures total power.
Automatically identifies transformer windings.
Identifies capacitive and inductive loads.
Identifies incorrect three-phase three-wire and three-phase four-wire wiring.
Large 50 mm jaw opening.
Large 71 mm × 52 mm LCD display.
Data hold function.
Stores up to 500 sets of measurement data.
LCD backlight.
Low-battery indication.
Automatic power-off function.
Built-in rechargeable lithium battery.
Portable and multifunctional design.
Suitable for power distribution system testing.
Suitable for industrial electrical maintenance and troubleshooting.
Suitable for transformer and electrical equipment testing.
Suitable for three-phase electrical system analysis.
Suitable for power measurement and electrical diagnostics.
Specifications:
AC Voltage: 0.00 V–600 V.
AC Voltage Accuracy: ± (1.5% rdg + 3 dgt).
AC Current: 0.0 mA–1000 A.
AC Current Accuracy: ± (1.5% rdg + 3 dgt).
Phase Range: 0.0°–360.0°.
Phase Accuracy: ±1°.
Active Power: 0.0 W–600 kW.
Active Power Accuracy: ± (3% rdg + 3 dgt).
Reactive Power: 0.0 VAR–600 kVA.
Reactive Power Accuracy: ± (3% rdg + 3 dgt).
Apparent Power: 0.0 VA–600 kVA.
Apparent Power Accuracy: ± (3% rdg + 3 dgt).
Frequency: 45 Hz–65 Hz.
Frequency Accuracy: ±0.1 Hz.
Power Factor: -1 to +1.
Power Factor Accuracy: ±0.03.
Jaw Opening: Ø50 mm.
Display: LCD, 71 mm × 52 mm.
Sampling Rate: 2 times/s.
Data Storage: 500 sets.
Data Hold: Yes.
Backlight: Yes.
Auto Power-Off: Yes.
Power Supply: DC 3.7 V rechargeable lithium battery.
Continuous Operating Time: 5 hours.
Product Dimensions: 187 × 191 × 51 mm.
Operating Temperature: -10°C to 40°C, <80% RH.
Storage Temperature: -10°C to 60°C, <70% RH.
Insulation: Double-insulated.
