Multi-channel Temperature Logger, UT3248+, 48 channels
SKU: UT3248-Plus
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
UT3200+ Series, Multi-channel Temperature Logger:
4.3-inch true-colour LCD screen.
6-digit display for the main parameter.
supports thermocouples of the K/N/E/J/T/R/S/B types.
Range of test: -200°C to 1800°C.
Resolution of the temperature test to 0.01 °C.
Fast and slow are the two scan speeds.
Automatic identification of thermocouple failures.
Graph display mode, column chart, and intuitive data display.
adjustment for cold junctions.
8G U disk, support for U disk storage, and a standard USB host interface.
When the power is turned off, file management settings will remain intact.
A standard 2-meter K-type thermocouple can monitor temperatures between 0 and 200°C.
Overrun reading colour change and overrun alert for temperature upper and lower limits.
LAN interface, standard RS-232C, SCPI, and Modbus protocol support.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UT3200+ Series, Multi-channel Temperature Logger.
Display mode Direct numerical reading, curve chart, histogram.
Type Thermocouple: J, K, T, E, S, N, B, R.
Measuring range -200.0° C-1800.0° C (the range will change with diff errant thermocouple model).
Resolution 0.01° C.
Scanning speed Fast, slow.
Sorting function Build-in data sorting can set upper/lower temperature limit alarm for each channel.
Alarm function Upper/lower temperature limit alarm.
User calibration User calibration of each channel is allowed.
Button functions Lock -- keyboard lock, Print Sc – screenshot.
Power AC 100-240V 50/60Hz.
Display mode 4.3-inch LCD screen.
Product size (W×H×D) 214mm×88.2mm×330.3mm.
