      Battery Tester, UT3513+: Micro Ohm Meter (20kΩ, accuracy: 0.05%)

      SKU: UT3513-Plus

      Out of stock

      Availability: Out of Stock

      Short Description
      The UT3513+ Micro Ohm Meter is a benchtop DC resistance tester that can accurately measure resistance from 1 µΩ to 20 k Ω. It is equipped with a minimum resolution of 1 µΩ, a maximum measurement rate of 100 readings per second, and an accuracy of up to 0.05%. The instrument has a 4.3-inch TFT LCD and several communication connections, making it ideal for laboratory testing, production-line quality control, automated test systems, and professional resistance measurement.
      UT3513-Plus
      Alternative image 1
      Features: DC resistance measurement from 1 µΩ to 20 k Ω. High accuracy of up to 0.05%. Minimum resolution of 1 µΩ. High-speed measurement up to 100 readings/s. 4.3-inch TFT LCD display. Multiple measurement modes: R, R-T, T, LPR and LPR-T. LPR low-voltage test mode to help protect the device under test. Automatic and manual measurement range selection. Four-terminal measurement for accurate low-resistance testing. Resistance sorting and PASS/FAIL judgement. Supports absolute tolerance, percentage tolerance and direct-reading comparison. Short-circuit full-range zeroing calibration. RS-232, RS-485, LAN and Handler interfaces. Supports SCPI and Modbus RTU protocols. Suitable for computer, PLC and WINCE device communication. Supports remote control and data acquisition. Compact ½ 2U benchtop form factor.   Specifications: Product Type: Micro Ohm Meter / DC Resistance Tester. Resistance Measurement Range: 1 µΩ–20 k Ω. Minimum Resolution: 1 µΩ. Basic Accuracy: 0.05%. Maximum Test Rate: 100 readings/s. Measurement Method: Four-terminal measurement. Measurement Modes: R / R-T / T / LPR / LPR-T. Low-Voltage Test Mode: LPR. Range Selection: Automatic / Manual. Sorting Function: PASS/FAIL. Comparison Methods: Absolute tolerance / Percentage tolerance / Direct-reading comparison. Calibration: Short-circuit full-range zeroing. Display: 4.3-inch TFT LCD. Communication Interfaces: RS-232 / RS-485 / LAN / Handler. Protocols: SCPI / Modbus RTU Applications: Laboratory testing / Production testing / Quality control / Automated test systems.
