Benchtop LCR Meters, UT622A: Handheld LCR Meters (10kHz, 0.1%)
SKU: UT622A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The UT622A Handheld LCR Meter is a high-precision, portable component tester that is ideal for use in laboratories, production lines, maintenance sites, and electronic component inspection.
It has a 2.8-inch TFT LCD, numerous test frequencies ranging from 100 Hz to 10 kHz, automatic LCR identification, and adjustable test signal levels.
The meter enables three- and five-terminal testing, as well as Kelvin test lead expansion for more precise measurements.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Maximum test frequency of 10 kHz.
Maximum basic accuracy of 0.1%.
Measures:
Inductance (L).
Capacitance (C).
Resistance (R).
Impedance (Z).
ESR.
Dissipation factor (D).
Quality factor (Q).
Phase angle (θ).
Auto LCR component identification.
Test frequencies: 100 Hz, 120 Hz, 1 kHz and 10 kHz.
Selectable test signal levels: 0.1 Vrms, 0.3 Vrms and 1 Vrms.
100 Ω output impedance.
Three-terminal test jacks.
Five-terminal test sockets.
Supports Kelvin test lead expansion.
Fast, medium and slow measurement speeds.
Measurement rates up to 20 readings/s.
Auto and hold ranging modes.
Series and parallel equivalent circuit modes.
Open/short circuit correction.
Tolerance mode for component sorting.
Tolerance range of 1%–20%.
PASS/FAIL LED indication.
Recording mode for average, maximum, minimum and number of readings.
Mini-USB connectivity.
2.8-inch TFT LCD, 320 × 240 pixels.
Rechargeable 3.7 V, 1800 mAh lithium-polymer battery.
Specifications:
Product Type: Handheld LCR Meter.
Maximum Test Frequency: 10 kHz.
Accuracy: 0.1%.
Display Count: 99,999.
Minimum Resolution: 0.0001.
Inductance (L): 0.001 µH–9999.9 H.
Capacitance (C): 0.001 pF–99.999 mF.
Impedance / Resistance (Z/R): 0.0001 Ω–99.999 MΩ.
ESR: 0.01 m Ω–999.99 Ω
Dissipation Factor (D): 0.0001–9.9999.
Quality Factor (Q): 0.0001–99999.
Phase Angle (θ): -179.9° to 179.9°.
Test Frequencies: 100 Hz / 120 Hz / 1 kHz / 10 kHz.
Test Signal Levels: 0.1 Vrms / 0.3 Vrms / 1 Vrms.
Output Impedance: 100 Ω.
Measurement Parameters: Primary: L/C/R/Z; Secondary: D/Q/θ/ESR.
Auto LCR: Yes.
Test Terminals: Three-terminal jacks / five-terminal sockets.
Test Rate: Fast: 20 readings/s; Medium: 5 readings/s; Slow: 2 readings/s.
Ranging Mode: Auto / Hold.
Tolerance Range: 1%–20%.
Equivalent Circuit Mode: Series / Parallel.
Correction: Open / Short circuit.
Tolerance Indicator: PASS: green / FAIL: red.
Communication Interface: Mini-USB.
Display: 2.8-inch TFT LCD, 320 × 240.
Battery: 3.7 V, 1800 mAh rechargeable lithium-polymer.
Product Dimensions: 90 × 190 × 44 mm.
