Benchtop LCR Meters, UT622C: Handheld LCR Meters (100kHz, 0.1%)
SKU: UT622C
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The UT622C Handheld LCR Meter is a portable, high-accuracy component tester with a 2.8-inch TFT LCD, 5-digit display, and a measuring rate of up to 20 readings per second.
It has test frequencies ranging from 100 Hz to 100 kHz with adjustable test signal levels of 0.1 V, 0.3 V, and 1 V.
The meter has automatic LCR identification, numerous measurement parameters, tolerance sorting, and recording capabilities, making it ideal for laboratory testing, production-line inspection, and electronic maintenance.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Maximum test frequency of 100 kHz.
Basic accuracy of 0.1%.
5-digit display.
Maximum test rate of 20 readings/s.
Measures:
Inductance (L).
Capacitance (C).
Resistance (R).
Impedance (Z).
ESR.
Dissipation factor (D).
Quality factor (Q).
Phase angle (θ).
Auto LCR component identification.
Test frequencies: 100 Hz, 120 Hz, 1 kHz, 10 kHz and 100 kHz.
Selectable test signal levels: 0.1 V, 0.3 V and 1 V.
100 Ω output impedance.
Three-terminal test ports.
Five-terminal end-face test ports.
Supports Kelvin test lead expansion.
Fast, medium and slow measurement speeds.
Auto and hold ranging.
Series and parallel equivalent circuit modes.
Open-circuit and short-circuit correction.
Tolerance mode for component sorting.
Tolerance range of 1%–20%.
PASS/FAIL comparison with LED indication.
Recording mode for average, maximum, minimum and number of readings.
Mini-USB connectivity.
Rechargeable lithium-polymer battery.
2.8-inch TFT LCD display.
Dual power supply: rechargeable battery or USB power adapter.
Specifications:
Product Type: Handheld LCR Meter.
Maximum Test Frequency: 100 kHz.
Basic Accuracy: 0.1%.
Display Count: 5-digit.
Maximum Test Rate: 20 readings/s.
Inductance (L): 0.001 µH–9999.9 H.
Capacitance (C): 0.001 pF–99.999 mF.
Impedance / Resistance (Z/R): 0.0001 Ω–99.999 MΩ.
ESR: 0.01 m Ω–999.99 Ω.
Dissipation Factor (D): 0.0001–9.9999.
Quality Factor (Q): 0.0001–99999.
Phase Angle (θ): -179.9° to 179.9°.
Test Frequencies: 100 Hz / 120 Hz / 1 kHz / 10 kHz / 100 kHz.
Test Signal Levels: 0.1 V / 0.3 V / 1 V.
Output Impedance: 100 Ω.
Primary Parameters: L / C / R / Z.
Secondary Parameters: D / Q / θ / ESR.
Auto LCR Identification: Yes.
Test Ports: 3-terminal / 5-terminal.
Test Speeds: Fast / Medium / Slow.
Fast Test Rate: 20 readings/s.
Medium Test Rate: 5 readings/s.
Slow Test Rate: 2 readings/s.
Ranging: Auto / Hold.
Equivalent Circuit: Series / Parallel.
Open/Short Correction: Yes.
Tolerance Range: 1%–20%.
PASS/FAIL Sorting: Yes.
Recording Mode: Average / Maximum / Minimum / Number of readings.
Connectivity: Mini-USB.
Display: 2.8-inch TFT LCD, 320 × 240 pixels.
Battery: 3.7 V, 1800 mAh rechargeable lithium-polymer.
DCR Measurement: No.
