Programmable DC Electronic Loads, UTL8212+, (1-Channel, 40A, 400W)
SKU: UTL8212-Plus
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
UTL8200+ Series, Programmable DC Electronic Loads:
UTL8211+: 400W, 150V, 40A.
UTL8212+: 2~200W, 150V/2~150V/20A.
The four basic modes are CC/CV/CR/CP.
1 mV/1 mA resolution is possible.
Voltage and current sample rate of up to 4.8 MHz
Battery discharge test with multiple modes.
List mode with automatic test support.
Test function for independent short circuits.
Numerous safeguards, including anti-reverse connections, overvoltage, low voltage, overcurrent, overpower, and overheating.
SCPI-compatible S232 communication interface.
Enabling remote operation and monitoring using host computer software.
Turn off the memory function.
Fan with intelligent temperature management.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTL8200+ Series, Programmable DC Electronic Loads.
Input ratings 0-40° C Voltage 0-150V.
CV mode Range 0-150V.
CC mode Range 0-2A, 0-20A.
CR mode Range 0.05Ω-7.5KΩ.
Over-power protection Delay protection, immediate protection.
Over-current protection Delay protection, immediate protection.
Over-voltage protection Delay protection, immediate protection.
Over-temperature protection ≥85° C.
Interface & protocol RS232, RS485(optional) and SCPI protocol5KΩ.
Power 110V±10%/220V±10% Frequency 50/60Hz.
Display 2.8 inches LCD.
Product net weight 3.42kg.
Product size (W×H×D) 88mm x 174.6mm x 230mm.
