Programmable Switching Power Supplies, UTP1306 1-Channel
SKU: UTP1306
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
UTP1000 Series, Programmable Switching Power Supplies:
The UTP1300 series power supply is a cost-effective switch-type DC regulated power supply with a single output.
It provides a pure output, outstanding performance indications, and can suit a wide range of testing requirements.
Used for product debugging and maintenance, quality control and testing, automated production testing, training trials, and so on.
A single output.
Output: 32V, 6A/10A.
Resolution is 10 mV/1 mA.
Protection against overvoltage or current.
Three categories of one-key recall of stored data.
The overcurrent/voltage protection value can be set.
Independent output switch.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTP1000 Series, Programmable Switching Power Supplies.
Output voltage 0-32V.
Output current 0-6A.
Output power 192W.
Load regulation CV ≤0.1%+5mV.
Load regulation CC ≤0.2%+3mA.
Power regulation CV ≤0.01%+5mV.
Power regulation CC ≤0.2%+3mA.
Power Input voltage: 110V AC/220V AC, 50Hz-60Hz.
Display 4 digits LED.
Product size (W×H×D) 80mm x 150mm x 230mm.
