Non-Programmable Linear Power Supplies, UTP3303-II, DC, 3-Channel
SKU: UTP3303-II
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
UTP3300-II Series, Non-Programmable Linear Power Supplies:
Features include three-channel linear DC power supplies.
High-precision four-digit voltage and current display with 10mV/1mA resolution (UTP3300-II Series).
Minimal noise and ripple.
Constant voltage/current, OVP, OCP, OTP, and reverse polarity safety.
Series/parallel output function.
On/off control of the output.
Intelligent temperature control fan (only for the UTP3300-II Series).
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTP3300-II Series, Non-Programmable Linear Power Supplies.
Output voltage 0-32V (CH1, CH2),5V(CH3).
Output current 0-3A (CH1, CH2),3A(CH3).
Output power 207W.
Display mode 4-bit voltage and current dual display.
Power Input voltage: 115V AC/230V AC; Frequency: 47Hz-63Hz.
Display 4 windows, LED.
Product net weight 9.2kg.
Product size (W×H×D) 319mm×146mm×226mm.
