Non-Programmable Linear Power Supplies, UTP3313TFL-II, DC, 1-Channel
SKU: UTP3313TFL-II
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
UTP3300TFL-II Series, Non-Programmable Linear Power Supplies:
Single-channel linear DC power supplies from the UTP3000TFL-II series are affordable benchtop instruments for electronics manufacturing and testing, do-it-yourself projects, and other uses.
Lightweight and simple-to-use UI.
Linear DC power supply with a single channel.
Four-digit, high-precision voltage and current display with 10mV/1mA.
Minimal noise and ripple.
Constant voltage and current conversion with current limit protection that happens automatically.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTP3300TFL-II Series, Non-Programmable Linear Power Supplies.
Output voltage 0-30V.
Output current 0-3A.
Output power 90W.
Load regulation CV ≤0.01%+3Mv.
Load regulation CC ≤0.1%+5mA.
Reliability MTBF(e): ≥2000hrs.
Power Input voltage: 110V/220V±5% AC, Frequency: 50Hz/60Hz.
Display 4 digits LED.
Product net weight 3kg.
Product size (W×H×D) 105mm x 165mm x 249mm.
