Benchtop LCR Meters, UTR2830E: (100kHz, 0.05%)
SKU: UTR2830E
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The UTR2830E Benchtop LCR Meter is a high-performance digital bridge that allows for precise measurement and quality inspection of electronic components.
It can measure characteristics including inductance, capacitance, resistance, impedance, quality factor, dissipation factor, and DCR.
The instrument includes a 4.3-inch TFT LCD, multi-parameter display, multi-level comparator sorting, programmable list sweep testing, and open/short/load calibration.
Its RS-232, Handler, USB Host, USB Device, and optional LAN interfaces make it ideal for on-line quality assurance, inbound inspection, and automated production testing.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Maximum test frequency of 100 kHz.
Basic accuracy of 0.05%.
6-bit display.
Maximum test rate of 80 readings/s.
DCR (DC resistance) measurement.
Measures multiple parameters including:
Inductance (L).
Capacitance (C).
Resistance (R).
Impedance (|Z|).
Dissipation factor (D).
Quality factor (Q).
Admittance (|Y|).
Conductance (G).
Reactance (X).
Phase angle (θ).
DCR (RDC).
AC voltage (Vm).
AC current (Im).
4.3-inch TFT LCD, 480 × 272 pixels.
Multi-parameter display with up to four measurement parameters simultaneously.
Multi-reference comparator for fast component quality determination.
10-level filtering.
10-level comparator sorting.
List sweep testing with up to 201 points.
Frequency, AC voltage, AC current and DC bias sweep capability.
Open circuit, short-circuit and load calibration.
Relative value measurement.
Vm/Im monitoring.
Automatic level adjustment.
Series and parallel equivalent circuit modes.
Auto and hold range modes.
Internal, manual, external and bus trigger modes.
Data averaging from 1–255 readings.
Internal storage for test settings and results.
USB storage support.
RS-232, Handler, USB Host and USB Device interfaces.
LAN interface available as an option.
Suitable for production quality assurance, incoming inspection and automated production testing.
Specifications:
Product Type: Benchtop LCR Meter / LCR Digital Bridge.
Frequency Range: 20 Hz–100 kHz.
Maximum Test Frequency: 100 kHz.
Basic Accuracy: 0.05%.
Display Count: 6-bit.
Maximum Test Rate: 80 readings/s.
DCR Measurement: Yes.
AC Test Level: 10 mVrms–2 Vrms.
AC Level Accuracy: ± (10% × Set Value + 2 mV).
AC Source Resistance: 100 Ω standard; 30 Ω / 50 Ω / 100 Ω selectable with ISO OFF.
Resistance (R): 0.00001 Ω–99.9999 MΩ.
Reactance (X): 0.00001 Ω–99.9999 MΩ.
Conductance (G): 0.00001 µS–99.9999 S.
Inductance (L): 0.00001 µH–99.9999 kH.
Capacitance (C): 0.00001 pF–9.99999 F.
Dissipation Factor (D): 0.00001–9.99999.
Quality Factor (Q): 0.00001–99999.9.
Phase Angle (θd): -179.999° to 179.999°.
DCR: 0.00001 Ω–999.999 MΩ.
Test Speed: Fast: 12.5 ms; Medium: 83 ms; Slow: 167 ms.
Test-Side Configuration: 5-terminal.
Calibration: Open / Short / Load.
List Scan: Up to 201 points.
Equivalent Mode: Series / Parallel.
Range Mode: Auto / Hold.
Trigger Modes: Internal / Manual / External / Bus.
Average Times: 1–255.
Comparator: 10-level sorting; BIN1–BIN9, NG, AUX.
Storage: Internal and USB memory.
Interfaces: RS-232 / Handler / USB Host / USB Device / Optional LAN.
Display: 4.3-inch TFT LCD, 480 × 272.
Power Supply: AC 110 V / 220 V, 50/60 Hz.
Dimensions: 210 × 86 × 360 mm.
