Spectrum/Signal Analyzers, UTS3000-AMA
SKU: UTS3000-AMA
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
UTS3000T+ Series, Spectrum/Signal Analysers:
The frequency measurement ranges from 9 kHz to 1.5 GHz, 3.2 GHz, 3.6 GHz, and 8.4 GHz.
The display average noise level can be as low as -161 dBm (typical value).
Phase noise is less than -98 dBc/Hz (offset 10 kHz is common).
Full amplitude accuracy is <0.7 db.
Minimum resolution bandwidth (RBW): 1 Hz.
Advanced function: one key measurement (optional).
The EMI pre-compliance analysis function is optional.
Analog demodulation analysis support is optional.
Support the tracking of the source output function.
10.1-inch HD capacitive touch screen with a resolution of 1280 x 800.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTS3000T+ Series, Spectrum/Signal Analysers.
UNI-T UTS3000-AMA Analog Demodulation Analysis Option.
Demodulation.
Frequency Range (Spectrum Analyzer Model Dependent): - 2 MHz to 2.1 GHz - 2 MHz to 3.6 GHz - 2 MHz to 8.4 GHz.
Carrier Power Accuracy: ±2 db.
Input Power: -30 dBm to +20 dBm (Automatic attenuation).
Carrier Power Display Resolution: 0.01 dBm, AM Measurement.
Modulation Rate: 20 Hz to 100 kHz.
Accuracy: 1 Hz (Nominal) for Modulation Rate < 1 kHz, < 0.1% Modulation Rate (Nominal) for Modulation Rate ≥ 1 kHz.
Depth: 5% to 95%.
Depth Accuracy: ±4% (Nominal), FM Measurement.
Modulation Rate: 20 Hz to 100 kHz.
Accuracy: 1 Hz (Nominal) for Modulation Rate < 1 kHz, < 0.1% Modulation Rate (Nominal) for Modulation Rate ≥ 1 kHz.
Frequency Offset: 1 kHz to 400 kHz.
Frequency Offset Accuracy: ±4% (Nominal), PM Measurement.
Modulation Rate: 20 Hz to 100 kHz.
Accuracy: 1 Hz (Nominal) for Modulation Rate < 1 kHz, < 0.1% Modulation Rate (Nominal) for Modulation Rate ≥ 1 kHz.
Phase Deviation: 0.2 to 6.28 rad.
Phase Deviation Accuracy: ±4% (Nominal).
