Signal Analyzers, UTS3000-AMK
SKU: UTS3000-AMK
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
UTS3000T+ Series, Spectrum/Signal Analysers:
The frequency measurement ranges from 9 kHz to 1.5 GHz, 3.2 GHz, 3.6 GHz, and 8.4 GHz.
The display average noise level can be as low as -161 dBm (typical value).
Phase noise is less than -98 dbc/Hz (offset 10 kHz is common).
Full amplitude accuracy is <0.7 db.
Minimum resolution bandwidth (RBW): 1 Hz.
Advanced function: one key measurement (optional).
The EMI pre-compliance analysis function is optional.
Analog demodulation analysis support is optional.
Support the tracking of the source output function.
10.1-inch HD capacitive touch screen with a resolution of 1280 x 800.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTS3000T+ Series, Spectrum/Signal Analysers.
Power Measurement:
Channel Power: Channel Power, Power Spectral Density.
ACP (Adjacent Channel Power): Main Channel Power, Left Channel Power, Right Channel Power.
Occupied Bandwidth: Occupied Bandwidth, Transmit Frequency Error.
Time Domain Power: Zero Span Integrated Power.
CNR (Carrier-to-Noise Ratio): C/N, Noise Power.
Non-Linear Measurement:
TOI (Third-Order Intercept): Measure third-order products from two tones.
Harmonic Measurement: Max Harmonic Number 10.
Spectrum Monitor Measurement: - Spectrogram.
