Spectrum/Signal Analyzers, UTS3000-EMI
SKU: UTS3000-EMI
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
UTS3000T+ Series, Spectrum/Signal Analysers:
The frequency measurement ranges from 9 kHz to 1.5 GHz, 3.2 GHz, 3.6 GHz, and 8.4 GHz.
The display average noise level can be as low as -161 dBm (typical value).
Phase noise is less than -98 dbc/Hz (average value at 10 kHz offset).
Full amplitude accuracy is <0.7 db.
Minimum resolution bandwidth (RBW): 1 Hz.
Advanced function: one key measurement (optional).
The EMI pre-compliance analysis function is optional.
Analog demodulation analysis support is optional.
Support the tracking of the source output function.
10.1-inch HD capacitive touch screen with a resolution of 1280 x 800.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTS3000T+ Series, Spectrum/Signal Analysers.
EMI Analysis Option for the UTS3000B/T Series Spectrum Analysers.
EMI Resolution Bandwidth:
Resolution Bandwidth (-6dB): 200 Hz, 9 kHz, 120 kHz, 1 MHz.
Resolution Bandwidth Precision: < 5% (Nominal).
EMI Detector: - Types: Peak, Negative Peak, Quasi Peak, EMI Average, Average.
EMI Main Functions:
Standards Supported: CISPR.
View Options: Scan table, Meter, Signal table.
Meter Control and Average Settings.
Compliance Limits: AS-NZS, Bell Core, DEF-STAN, DO-160, EN, FCC, GB9254, MIL-461, VCCI, and Custom.
Table Settings: Signal table settings, Scan table settings.
Scan Sequences: Scan, Search, Scan-Search-Meas, Scan-Search, Search-Meas, Measure.
Signal Detector.
Output Reports.
