Signal Analyzers, UTS3000A-B40
SKU: UTS3000A-B40
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
UTS3000A Series, Signal Analysers:
Frequency range: 9 kHz to 8.4 GHz.
DANL: -165 dBm (typical).
Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
Scan up to 40,001 points.
Minimum resolution bandwidth (RBW): 1 Hz.
Support sophisticated one-key measurements (optional).
EMI Analysis Function (Optional).
Analog demodulation analysis support is available (optional).
Support Digital Demodulation Analysis (optional).
Support real-time spectrum analysis.
Support I/Q analysis (optional).
Support Vector Network Analysis.
10.1-inch high-definition capacitive touchscreen display.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTS3000A Series, Signal Analysers.
Expands Standard RTSA from 10 MHz to 40 MHz
Real-Time Spectrum Analysis Bandwidth: Expands from 10 MHz to 40 MHz with this option.
Signal Duration for 100% POI at Full-Scale Accuracy: - Maximum Span (Kaiser window): 6.68 μs.
Detection Modes: Peak, Negative Peak, Sample, Average.
Trace Display Options: Normal, Density, Spectrogram, PVT, PVT Spectrum, PVT Spectrogram, Power gram, Power gram Spectrogram.
Resolution Bandwidth (RBW): 6 RBW options for each window, except the rectangle window.
Frequency Span: - Min: 133.3324 kHz, Max: 4.2716 MHz (for 40 MHz bandwidth) - 25 MHz Span: Min: 66.6662 kHz, Max: 2.1358 MHz - 10 MHz Span: Min: 33.3331 kHz, Max: 1.0679 MHz
Trigger Options: Free run, External trigger, Power (time), Frequency Mask Template (FMT).
Dynamic Range: 200 dB Bitmap colour.
History Depth: 10,000.
