Signal Analyzers, UTS3000A-TDD-LTE
SKU: UTS3000A-TDD-LTE
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
UTS3000A Series, Signal Analysers:
Frequency range: 9 kHz to 8.4 GHz.
DANL: -165 dBm (typical).
Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
Scan up to 40,001 points.
Minimum resolution bandwidth (RBW): 1 Hz.
Support sophisticated one-key measurements (optional).
EMI Analysis Function (Optional).
Analog demodulation analysis support is available (optional).
Support Digital Demodulation Analysis (optional).
Support real-time spectrum analysis.
Support I/Q analysis (optional).
Support Vector Network Analysis.
10.1-inch high-definition capacitive touchscreen display.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTS3000A Series, Signal Analysers.
TDD-LTE (Time Division Duplex Long-Term Evolution) demodulation analysis is used to evaluate and troubleshoot the performance of TDD-LTE wireless communication systems, where uplink and downlink transmissions share the same frequency but occur at different times.
This analysis focuses on assessing the quality and integrity of the modulated signal, including parameters such as modulation schemes (QPSK, 16QAM, etc.), signal-to-noise ratio (SNR), error vector magnitude (EVM), and timing synchronization.
By conducting TDD-LTE demodulation analysis, engineers can identify signal impairments, detect timing and synchronization issues, optimize resource allocation, and ensure the overall performance of the network.
This is especially important in environments with heavy data traffic or interference, helping maintain efficient and stable communication in mobile networks.
With the UNI-T UTS3000A Signal Analyzer UTS3000A-TDD-LTE option enabled, you can affordably perform simple and complex analysis of your LTE signal.
