Spectrum/Signal Analyzers, UTS3032T+: 3.2 GHz, 1Hz-1 MHz, -161 dBm
SKU: UTS3032T-Plus
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
UTS3000T+ Series, Spectrum/Signal Analysers:
The frequency measurement ranges from 9 kHz to 1.5 GHz, 3.2 GHz, 3.6 GHz, and 8.4 GHz.
The display average noise level can be as low as -161 dBm (typical value).
Phase noise <-98 dBc/Hz (the usual value is off at 10 kHz).
Accuracy of full amplitude <0.7 dB.
1 Hz is the minimum resolution bandwidth (RBW).
Measurement of advanced function one key (optional).
EMI function for pre-compliance analysis (optional).
Analog demodulation analysis support is optional.
Support the source output tracking feature.
10.1-inch capacitive touch screen, 1280 x 800 HD.
An HD multi-touch screen for speedy operation HD screen with multiple touches for speedy operation.
High sensitivity for testing a weaker signal.
Higher frequency resolution is provided by 40,001 sweep points.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTS3000T+ Series, Spectrum/Signal Analysers.
Frequency range 9 kHz-3.2 GHz.
Frequency resolution 1Hz.
Sweep accuracy Swept ± [0.25%*Span Span/(Points-1)], FFT ± [0.10%*Span Span/(Points-1)].
Sweep time 1 ms to 4000 s (span≠ 0), 1 μs to 4000 s (span= 0).
Sweep mode Swept, FFT.
Marker mode Normal, Delta Δ, Fixed.
Marker function Marker Noise, Band Power, Band Density, NdB, Counter.
Bandwidth accuracy (–3dB) < 5% (nominal).
Power 100-240V AC, 50Hz/60Hz, 100 to 120 VAC (Fluctuations±10%),400 Hz.
Display 10.1 'TFT LCD (1280x800) touch.
Product size(W×H×D) 378 mm×218 mm×120 mm.
Product net weight 4.55kg.
