Signal Analyzers, UTS3060A 6.0GHz Performance-Series Signal Analyzer
SKU: UTS3060A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
UTS3000A Series, Signal Analysers:
Frequency range: 9 kHz to 8.4 GHz.
DANL: -165 dBm (typical).
Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
Scan up to 40,001 points.
Minimum resolution bandwidth (RBW): 1 Hz.
Support sophisticated one-key measurements (optional).
EMI Analysis Function (Optional).
Analog demodulation analysis support is available (optional).
Support Digital Demodulation Analysis (optional).
Support real-time spectrum analysis.
Support I/Q analysis (optional).
Support Vector Network Analysis.
10.1-inch high-definition capacitive touchscreen display.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTS3000A Series, Signal Analysers.
Frequency Range 9kHz–6.0GHz.
RBW 1Hz-10MHz, step with 1-3-10.
DANL -165dBm/Hz.
Traces 6.
Scan Points 40,001.
Tracking Generator Included.
Display Size (in) 10.1in.
Touchscreen Yes.
Warranty 3 years.
Product Dimensions (L x W x H) 15 in x 9 in x 5 in.
Product Weight 10 lb.
Certifications CE/cETLus/UKCA.
