Signal Analyzers, UTS5013A: 13.6 GHz, 1Hz-8 MHz, -163 dBm
SKU: UTS5013A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
UTS5000A Series, Signal Analysers:
Range of frequencies: 9 kHz to 26.5 GHz.
DANL: -163 dBm (average).
Phase noise: less than -107 dBc/Hz at 10 kHz offset.
Up to 100001 points can be scanned.
1 Hz is the minimum resolution bandwidth (RBW).
Allow for sophisticated one-key measuring (optional).
Function for EMI Analysis (optional).
Analogue Demodulation Analysis Support (optional).
Encourage the analysis of digital demodulation (optional).
I/Q Analysis Support (optional).
Configuration: 15.6-inch thin-film transistor LCD display with high definition, 1920x1080.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
UTS5000A Series, Signal Analysers.
Frequency range 9kHz-13.6 GHz.
Frequency resolution 0.001Hz.
Sweep width range 0Hz,10Hz-13.6GHz.
Sweep accuracy Swept: ± [0.25%×span horizontal resolution].
Sweep accuracy FFT: ± [0.10%×span horizontal resolution].
Sweep time Span ＝ 0 Hz, 1 μs to 6000 s; Span ≥ 10 Hz, 1 ms to 4000 s.
Advanced Measurement Power Suite Measurement, Nonlinear Measurement, Spectrum Monitoring.
Modulation Analysis AM Measurement, FM Measurement.
Power 100-240V AC (±10%), 50Hz/60Hz, 100 to 120 VAC (Fluctuations±10%) 400 Hz.
Display 15.6'TFT LCD (1920x1080) touch.
Product size(W×H×D) 445mm×311mm×195mm.
Product net weight 11kg.
