Specifications:

• Operational voltage ranges from 200 – 600 VAC.
• Rated Frequency: 50–60 Hz (± 5 Hz).
• Index Rating: Trip Class 10: 3.5–17: 90–5 (Trip Class 20 and 30).
• Starts per hour Standard: 5 starts and stops per hour (40 with the fan option).
• Internally bypassed: Yes.
• OLED screen.
• Control Supply: Standard 24 VDC, 110 to 230 VAC with Power Supply Option.
• Inputs: 2 digital and 1 programmable.
• Overload: Full I2T Motor Overload with Memory.
• Communication protocol: Modbus RTU.
• Yes, full logging functionality is available with commissioning software.
• IP/NEMA rating: IP20/NEMA Class 1 (*with finger guard fitted).
• Ambient temperature ranges from 4°–104°F (-20°–40°C) without de-rating and 140°F (60°C) with de-rating.
• Standards: UL, RCM, and CE.
• Languages: English, French, German, Spanish, Portuguese, and Italian.
• 2-year warranty.
• 192 amps.
• Trip Class 10 AC-53a 3.5-17: 90-05⁴.
• Trip Class 20 AC-53a 4-19: 90-5⁴.
• Trip Class 30 AC-53A Amps 200V 4-29: 90-5⁴.
• Dimensions (mm): 296 x 147 x 238.
• Weight in kg: 6.3.

Event logging:

• VMX-agility™ life event logging is a special feature that monitors the last 1600 events, enabling fast, reliable fault analysis and resolution.
• Recording various activities such as start, stop, top of ramp, faults, application parameters (time, overload level, currents, frequency), and device information.
• Event logs can be downloaded through the VMX-agility commissioning software or through a USB interface.

Soft stopping:

• Water hammers can be eliminated with Soft Stop Control.
• When you activate the stop signal, your pump motor's output torque gradually decreases.
• Check valves are now softly shut, and other parts of the fluid system are spared the force and potentially catastrophic effects of a water hammer.
