Specifications:

• The range is 17–477A, or 10-400 horsepower.
• 3-phase SCR.
• Memory provides full motor overload.
• Standard Trip Class 10: 3 x 23 or 3.5 x 17 seconds.
• 3 or 5 starts each hour (Trip Classes 20 and 30 are customizable).
• Volts: 208, 230, 400, and 480.
• Operates at frequencies ranging from 45 Hz to 65 Hz.
• Bypassed internally.
• NEMA 1, IP00, and IP20.
• A full-colour touch screen is easy to use.
• Fully automatic set-up.
• Control voltages: 110/230 VAC and 24 VDC.
• Energy Recovery System (iERS) as a standard feature.
• In a delta or 6-wire connection.
• Multiple languages.
• Modbus RTU is standard, with other protocols available as an option.
• Input/Output:
• 4 x programmable output relays.
• 3 programmable digital inputs.
• Input and output in analogue.
• USB for data logging and parameter setting and saving.
• Thermistor.
• Comprehensive data logging.
• Fully field-upgradable through a USB port.
• Fans are fully field-serviceable.
• 2-year warranty.
• 96 Amps.
• Trip class 10 AC-53a; 3,5-17: 90-5; 3-23: 90-5.
• Trip class 20 AC-53a; 4-19: 90-5.
• Trip class 30 AC-53a; 4-29: 90-5.
• Dimensions (mm): 270 x 95.2 x 177.1.
• Weight: 3.5 kg.

Event logging:

• The VMX-synergy™ data logger records all events, allowing for fast, reliable fault analysis and resolution.
• Recording various activities such as start, stop, top of ramp, faults, application parameters (time, overload level, currents, frequency), and device information.
• Event logs can be obtained by using a USB port or VMX-synergy™ commissioning software.

Soft stopping:

• Water hammers can be eliminated with Soft Stop Control.
• When you activate the stop signal, your pump motor's output torque gradually decreases.
• Check valves are now softly shut, and other parts of the fluid system are spared the force and potentially catastrophic effects of a water hammer.
