XBC SU-Type, Standard Base Unit, 100-240 V AC
SKU: XBC-DP20SU
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
The micro-PLC that provides maximal automation at the lowest possible cost is the XGB series.
With its excellent functionality and performance, it can handle tasks ranging from easy control to difficult ones.
XGB has a user-friendly interface along with multiple network monitoring and diagnosis features, as well as a backup function.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
AC110/240V power supply.
Relay output rating: 2A Resistive.
Max. I/O points: 384.
Analogue input resolution: 14-bit.
Analogue output resolution: 14-bit.
12 DC24 input.
8 Transistor (Source) output.
2 option slots.
Processing speed: 94ns/Step.
Program capacity: 15Kstep / 200KB.
Max. I/O points: (Main + Expansion 7 stages) 254 points.
RS-232C / RS-485(2 channel) Pulse catch.
Input filter External interrupt.
Size: 135 x 64 90 mm.
PID control High-speed counter Positioning Categories.
XBC-SU Standard PLC (Master-K), Max 7 Exp Cards, 2x Option Mod.
Master-K PLC, 100-240V AC, USB, 90 n/s Step, Max 7 Exp. Cards & 2x XBO Options, HSC, Pos.
Key benefits:
Compact.
Cost-effective.
LADDER and IEC-1131 programmable.
From 38 to 284 I/O points.
From 94 ns/step to 240 ns/step.
From 4 to 200 K steps.
