Modbus TCP adapter
SKU: XEL-BSSA
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Features:
LS PLC SMART I/O XEL-BSSA MODBUS TCP XGT Series RJ-45 2 Port module.
IEEE 802.3 standard.
MODBUS/TCP.
10/100BASE-TX media.
Ethernet Twisted pair 2ports (RJ-45).
2channels Ethernet MAC.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
I/F:
Protocol: Modbus TCP.
Transmission speed: 10/100Mbps.
Connector: RJ-45 (2ports).
Topology: Software (BootpServer).
IP Setup: Bus, Star.
Max. expansion module: 8ea.
Max. Digital I/O Point: 256 Points.
Max. Analog I/O Channel: 32ch (Input 16ch, output 16ch)
Operating Power:
Rated voltage: DC 24V.
Range: DC19.2 – 28.8V.
Rated Current: 1.5A.
Insulation: Non-Insulation, Comm, Part Insulation.
