Standard EtherCat Network 4axis
SKU: XGF-PN4B
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
XGT Positioning Module Features (Network Type:)
Direct connect with servo driver Max 8.
2~8 axis linear interpolation, 2axis circular interpolation, 3axis helical interpolation.
Position, speed, feed control is possible through the various operation.
Parameters, the operation data stored in the FRAM (without Battery).
CAM for controlling up to eight different types of CAM data.
Motion Control Beckhoff Bus.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Number of axis: 4 axis.
Interpolation: 2-8 axis linear, 2axis circular, 3axis helical interpolation.
Control method: Position, speed, Speed/position, position/speed position/torque, feed control.
Setting unit: Pulse, mm, inch, degree.
Position Data: Each axis has 400 data items (Operation step number 1-400, it is available to set with software package or programming.
Back-up: FRAM (parameter, operation data) no battery.
Manual: Jog/MPG/inching.
Homing method: Max+Z (Forward), Min+Z (Backwards), Near-point+Z (Forward, Backward), Max+near-point+Z (Forward), Min+near-point+Z (Backward), Z (Forward, Backward), near-point (Forward, Backward).
The ability to change speed: Absolute/Precent.
Torque: Rated torque %.
Absolute position System: 0 (Absolute encoder type servo).
Communication Cycle: 800 µs.
Max. distance: 100m.
Cable: STP (Shield Twisted pair) cable.
Error display: LED.
Operation display: LED.
Occupied points of I/O: 64 Points (Fixed type), 16 points (Variable type).
Current consumption (mA): 500mA.
Weight: 115g.
Encoder Input
Channel: 2Channel.
Max. Input: Max. 200 Kpps.
Input method: Line-drive input (RS-422A IEC), open collector output type.
Type: CW/CCW, Pulse/Dir, Phase A/B.
Connector: 12 Pin connector.
