I/O Mixed Module 16 points Input DC24, Output Sink
SKU: XGH-DT4A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
A flexible input/output module for use in industrial automation systems is the LS Electrical XGH-DT4A.
It has 16 transistor (NPN type) output points that can handle DC 12/24V at 0.1A and 16 DC 24V input points that can be used as current source or sink inputs.
As a member of the XGT series, this module is renowned for its dependability and effectiveness in handling challenging control duties.
Applications needing accurate control and monitoring are best suited for the XGH-DT4A, which integrates seamlessly into a variety of automation configurations.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Common (COM): 16 points/COM
Operation display: LED lighting when output is on
Internal current consumption: 100mA
External connection: 40-point connector
Weight (kg): 0.1
LS High Performance, Rack-Type PLC, XGI / XGR / XGK
Hybrid Digital I/O Modules
Input/ output mixed type
