XGT Network Module, Profibus-DP [Pnet] system, Slave, EN50170 / DIN 19245
SKU: XGL-PSEA
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Features:
Protocol for Profibus-DP.
Communicates with a distributed slave I/O device and a master automation device.
Without an application layer, quick slave communication is possible.
Speed of transmission: 9.6 Kbps to 12 Mbps.
Maximum transmission distance: 1,200 meters.
32 slave stations each segment, with a maximum of 126 slave stations accessible.
N Configurator/XG5000 is used for network configuration (diagnostic, monitoring, and parameter setting).
Master station I/O data: 7 kbytes.
Network slave modules are automatically monitored by Auto-scan (XG5000).
Multi-master.
N Configurator/XG5000 is an easy configuration tool.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Standard: EN50170/DIN19245
Interface: RS-485 (Electric)
Media access: Polling
Topology: Bus
Modulation: NRZ
Network interface: Auto baud rate.
Master/slave: slave
Max. number of slave per network: 99
Max. number of slave per segment: 32
Cable: shielded twisted pair cable
Max. I/O data 244 byte
Configuration tool: XG5000
Max. number of node: 99 (0-98)
Max. number of transmission block: 24
Current consumption: 410mA
