ZB7309-R001 EtherCAT-/Ethernet cable
SKU: ZB7309-R001
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
EtherCAT/Ethernet cable, no overall shield, PVC, fixed installation, 5 G 4 mm² + (1 x 4 x AWG22), black with yellow stripe, OD = 13.8 mm (±0.2 mm)
Length: 100 m
Buy currently uses Select Automation shop pricing and checkout.
Cross-section (Ethernet): 1 x 4 x 0.34 mm² (AWG 22)
Cross-section (power): 5 x 4.0 mm² (approx. AWG12)
Use: fixed installation
Material jacket: PVC (polyvinyl chloride)
Outer cable diameter: 13.8 mm ± 0.2 mm (0.543" ± 0.0079")
Jacket color: black (similar to RAL 9005) with yellow stripe (similar to RAL 1003)
