M8 plug field assembly ZS7000-0002
SKU: ZS7000-0002
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
M8 plug field assembly for EtherCAT P cables. plug, field assembly, EtherCAT P, IP65/67, screw type, straight, male, 4-pin, P-coded, Ø 4.9…6.5 mm, shielded
Buy currently uses Select Automation shop pricing and checkout.
Shielding: yes
Installation size: M8
Connector type: plug
Contact type: male
Number of positions (face): 4-pin
Coding: P-coded
Wire termination: screw connection
Max. wire cross-section: AWG26...AWG20 (0.14 mm²...0.5 mm²)
Max. cable outer diameter: 4.9 - 6.5 mm
Body color: metal
A1: 47.00 mm
A2: 14.00 mm
