KLIPPON BDX M20 S Stainless steel (316L)
Description:
- A specific compensating element called the Klippon BDX M20 S (2519550000) is made to make sure electrical enclosures have enough ventilation and drainage.
- This part is from the renowned Klippon BDX series, which is renowned for its dependable and high-quality performance in challenging settings.
- Because it is composed of stainless steel 1.4404 (316L), it has exceptional resistance to corrosion and adverse environments.
- By keeping moisture at bay and guaranteeing ideal airflow, the Klippon BDX M20 S is especially helpful in preserving the longevity and integrity of electrical installations.
Specifications:
- Component: Compensating element for ventilation and drainage.
- Series: Klippon BDX.
- Material: Stainless steel 1.4404 (316L).
- Protection Class: IP66.
- Dimensions:
- Height: 12 mm.
- Width: 27 mm.
- Length: 22 mm.
- Weight: 60 g.
- Temperature Range: -60°C to +200°C.
- Installation:
- Designed for bottom-side installation with vertical alignment.
- Thread upwards at the lowest point to permit proper drainage.
- Standards:
- REACH conforms.
- RoHS conforms.
Brand | Weidmuller |
---|
